20°C To 70°C FWDM Equipment Providing 2 To 40 Channels Designed For Optical Network Signal Routing And Data Transmission

Product Description:

The WDM Mux Demux is an advanced optical device designed to efficiently multiplex and demultiplex multiple wavelengths of light onto a single optical fiber, providing a streamlined solution for modern fiber optic communication networks. This device plays a crucial role in Wavelength Division Multiplexing (WDM) systems by combining (multiplexing) several optical signals at different wavelengths onto one fiber and separating (demultiplexing) them at the receiving end. By utilizing this technology, network operators can significantly increase the capacity and scalability of their fiber optic infrastructure without the need for laying additional fibers.

One of the key features of this WDM Mux Demux product is its flexibility in channel configuration. It supports a wide range of channels, from 2 up to 40, allowing users to customize the number of multiplexed wavelengths according to their specific network requirements. This makes it an ideal choice for various applications, from small-scale local area networks to large, complex metropolitan and long-haul fiber optic systems. The ability to tailor the number of channels ensures optimal use of available bandwidth while maintaining high performance and reliability.

Customization extends beyond channel count to include fiber length and connector types, providing a highly adaptable solution that can be tailored to fit diverse deployment scenarios. The fiber length can be customized to meet the exact needs of the installation site, whether it is a short-distance connection within a building or a long-distance link between data centers. Similarly, connector options are fully customizable, enabling seamless integration with existing network equipment and infrastructure. This flexibility minimizes additional hardware requirements and installation time, resulting in cost-effective deployment.

Performance is a critical factor in the design of this WDM Mux Demux. It boasts an impressive return loss of ≥ 45 dB, which ensures minimal signal reflection and loss within the system. High return loss is essential for maintaining signal integrity and preventing interference, especially in high-speed data transmission environments. This level of performance guarantees that the multiplexed signals remain clear and stable over long distances, contributing to the overall reliability of the network.

Moreover, the operating temperature range of -20°C to +70°C makes this device suitable for use in a variety of environmental conditions. Whether deployed in controlled indoor environments or harsh outdoor settings, the WDM Mux Demux maintains consistent performance and durability. This wide temperature tolerance is particularly beneficial for telecommunications providers and data center operators who require equipment that can withstand temperature fluctuations without compromising functionality.

In summary, the WDM Mux Demux is a versatile and robust solution for enhancing fiber optic communication networks. By efficiently multiplexing and demultiplexing multiple wavelengths, it maximizes the utilization of fiber infrastructure, reduces costs, and supports network scalability. Its customizable features—including channel count, fiber length, and connectors—combined with superior return loss and broad operating temperature range, make it an excellent choice for a wide range of applications. Whether for expanding existing networks or building new ones, this WDM Mux Demux product delivers reliable performance and flexibility to meet the evolving demands of modern optical communications.

Features:

• Product Name: WDM Mux Demux
• Connectors: Customized to meet specific requirements
• Operating Band: C Band for optimal performance
• Fiber Length: Customized according to application needs
• Channel Capacity: Supports 2 to 40 channels
• Return Loss: ≥ 45 dB ensuring minimal signal reflection
• High-quality fiber WDM technology for efficient wavelength management
• Effective WDM DEMUX functionality for separating multiplexed signals
• Reliable MUX performance for combining multiple wavelengths into a single fiber

Technical Parameters:

Applications:

The OEM WDM Mux Demux, model number WDM, is a high-performance fiber optic device designed to optimize the use of the C Band operating spectrum in fiber WDM networks. Manufactured in Shenzhen, China, this product boasts certifications including CE, ROSH, and REACH, ensuring compliance with international quality and environmental standards. With a channel capacity ranging from 2 to 40, it efficiently multiplexes and demultiplexes optical signals, making it ideal for various telecommunication and data transmission applications.

One of the primary application occasions for the OEM WDM Mux Demux is in metropolitan and long-haul optical networks where bandwidth expansion is crucial without laying additional fiber.

It supports CCWDM (Coarse Wavelength Division Multiplexing) technology, enabling multiple wavelength channels to be combined or separated simultaneously, thus maximizing the fiber capacity. This makes it particularly suitable for internet service providers, data centers, and enterprise networks aiming to enhance their network efficiency and scalability.

In addition, the WDM Mux Demux is widely used in scenarios such as fiber-to-the-home (FTTH) deployments, passive optical networks (PON), and wavelength routing in optical add-drop multiplexers (OADM). Its customizable fiber length and connectors provide flexibility to adapt to diverse network architectures and installation environments. The device’s excellent return loss of ≥ 45 dB ensures minimal signal reflection and high-quality transmission, which is critical in maintaining signal integrity over long distances.

The product is also favored in research and development environments for testing and validating wavelength division multiplexing systems. With a supply ability of 8000 units per day, standard export packaging, and a competitive price range of $20-80, OEM’s WDM Mux Demux offers fast delivery within 3-7 working days and convenient payment terms via T/T at once. Whether deployed in new network infrastructure or as an upgrade in existing systems, this WDM mux and demux device provides reliable performance and cost-effective bandwidth management.

Customization:

Our OEM WDM MUX Demux product offers extensive customization services to meet your specific needs. With model number WDM, this product is manufactured in Shenzhen, China, and holds CE, ROSH, and REACH certifications, ensuring high quality and compliance.

We support a minimum order quantity of just 1 unit, priced between $20 and $80, making it accessible for various scales of projects. Each WDM MUX is packed with standard export packaging to ensure safe delivery.

Our supply ability reaches up to 8000 units per day, with a delivery time of 3-7 working days. Payment terms are flexible, with T/T payment required at once for efficient processing.

The WDM MUX supports customization in fiber length and connectors, accommodating channels ranging from 2 to 40. It operates reliably within a temperature range of -20°C to +70°C and functions within the C Band operating band.

Whether you require mux and demux solutions tailored to your system or specific configurations of WDM MUX, our product customization services are designed to deliver precisely that with high performance and reliability.

Support and Services:

Our WDM Mux Demux product is designed to provide high-performance wavelength division multiplexing solutions for your optical network needs. For technical support, our team of experts is available to assist you with installation, configuration, troubleshooting, and maintenance to ensure optimal operation.

We offer comprehensive services including product training, system integration assistance, and customized solutions to meet your specific network requirements. Our support resources include detailed user manuals, application notes, and firmware updates accessible through our online portal.

To maximize the lifespan and efficiency of your WDM Mux Demux, we recommend regular system checks and adherence to the operational guidelines provided in the documentation. Our service team can also provide on-site support and preventive maintenance programs tailored to your schedule.

For any technical inquiries or to request service, please refer to the support section on our website where you will find FAQs, troubleshooting guides, and the latest software downloads. Our commitment is to ensure you receive timely and effective assistance to maintain the reliability of your optical network infrastructure.

Packing and Shipping:

The WDM Mux Demux product is carefully packaged to ensure maximum protection during transit. Each unit is enclosed in an anti-static bag to prevent electrostatic discharge, followed by a custom-fit foam insert that cushions the device against shocks and vibrations. The foam insert and product are then placed inside a sturdy, corrugated cardboard box designed to withstand rough handling.

For shipping, the packaged product is sealed securely and labeled with handling instructions, including “Fragile” and “This Side Up” to ensure proper orientation and care. We use reliable courier services with tracking options to monitor the shipment until it reaches the customer. Additionally, the packaging is designed to be compact and lightweight to optimize shipping costs while maintaining product safety.

We recommend inspecting the package upon delivery for any visible damage and reporting any issues immediately to ensure prompt resolution. Our packaging and shipping processes are continually reviewed and improved to guarantee that the WDM Mux Demux arrives in perfect condition and ready for deployment.

FAQ:

Q1: What is the brand and model number of this WDM Mux Demux product?

A1: The brand name is OEM and the model number is WDM.

Q2: Where is this WDM Mux Demux manufactured?

A2: It is manufactured in Shenzhen, China.

Q3: What certifications does this product have?

A3: This WDM Mux Demux product is certified with CE, ROSH, and REACH.

Q4: What is the minimum order quantity and the price range?

A4: The minimum order quantity is 1 unit, and the price ranges from $20 to $80 depending on specifications.

Q5: What are the packaging and delivery details?

A5: The product comes in standard export packing, with a delivery time of 3-7 working days.

Q6: What payment terms do you accept?

A6: We accept payment via T/T at once.

Q7: What is your supply capacity for the WDM Mux Demux?

A7: Our supply ability is 8000 units per day.
